Find Products by Model

Download

Product Lineup

Select by Application/Product Name

Transport

Pulse-control
motor-driven
Pick & place unit

Achieves high-speed and stable transport of workpieces
This product was developed for high speed, high precision, and compactness. Smooth X/Z transition, secure x-axis locking mechanism during Z operation.
This is a reliable PPU that brings together the technologies developed over many years of working with mechanized products.
Cam-driven
Pick & place unit

A proven loading unit
created by a wisdom cam mechanism
Robust design that supports high precision, high rigidity, and high loads. Smooth motion with movement displacement curve. Convenient and unrivaled on-site design. This is a lineup with a proven track record of pursuing the origins of PPU.
Pick up unit

Pick-up operation as fast as 30 ms
Combining advanced cam mechanisms accumulated over many years and reliable pneumatic equipment technology, we have produced a unit that softly picks up delicate workpieces, which are sensitive to shocks, at ultra-high speed. A unique mechanism improves the handling of delicate workpieces, making what was previously considered unstable now commonplace.

Grip

Parallel air chuck

Committed to gripping correctly
The ability to grab correctly is backed by an uncompromising design philosophy. The quality of MEPAC, which has been recognized with the Distinguished Invention Award and a track record of hundreds of thousands of products, is the result of continued dedication to making the chuck work the way they should.

Separate

ESCAPEMENT

Separation of continuously flowing workpieces made easy
It is said that automatic assembly begins with the correct separation and positioning of the workpieces to be assembled. The separation and positioning processes in preparation for assembly are often neglected, but the fundamentals of automated assembly would not be possible without the establishment of this elemental technology. Because correct separation is fundamental to the reliability of an automated assembly system.

Pitch Change

Pitch Change

Workpiece pitch change made easy and convenient
Pitch may need to be changed when transferring a large number of workpieces. We spent a great deal of time and effort to create our own products to meet the specifications of each device. MEG has developed a general-purpose unit that can freely change the pitch based on the cam technology we cultivated over many years. Achieves high-speed work with a small and simple mechanism, and repeats stable operation over a long period of time.

Determine Position

Turn Over

Turn over unit

High-speed, accurate turnover
Turning a part face down may seem simple, but it is complex due to its configuration of air actuators, is unstable even at low speeds, and requires a large amount of space. MEG's turn over unit employs a unique method that enables accurate turnover even at high speeds. It is used in a variety of applications such as manufacturing, inspection, and packaging.

Push

Cam pusher

Turn it lightly, and it will do the pushing work lightly with the force of the cam
By combining cam and stepping technologies cultivated over many years, the high-speed workpiece approach and powerful pushing motion are achieved with simple control by simply rotating the motor at a constant speed. Manual operation is also available for improved convenience. Use it for manufacturing sites for production equipment.

Indexing

Thin-type index unit

Proven compact index in pursuit of simplicity and convenience
Intermittent indexing devices used in automatic assembly systems are are required to be reliable as the main drive source for conveyance, sorting, etc. The INDEX is an integrated product with a simple indexing and locking mechanism that uses the internal Geneva system with a large indexing angle to enable smooth and high-speed driving while eliminating redundant mechanisms. This is a small index drive device incorporating a lot of ideas.
